LED HORTICULTURAL LIGHT FOR SEEDLINGS

Maximize growth with one of the most versatile LED horticultural lights in the industry. At ILUMINAR Lighting, we’ve designed a sleek, low-profile fixture specifically crafted for growing seedlings and hardening them off for the vegetative cycle.

The ILUMINAR Lighting iLW LED horticultural light creates the ideal environment for growing seedlings and plants in the early vegetative state. Its sleek, low profile engineering allows it to be equipped in low clearance, vertical agricultural farms and micro green environments making it the ideal LED horticultural light for most organic farmers.



Available in 40W and 60W configurations. The 40W and 60W LED arrays are 47.25 inches long (1.2m).


Installation is quick and easy with the ability to “daisy chain” several lights in a row with either the Dual, Triple or Quad connector. This feature reduces the number of power cords and electrical sockets needed when operating multiple fixtures in a confined area.

40W

Efficacy: 2.5 μmol/J

PPF: 100 μmol/s

60W

Efficacy: 2.5 μmol/J

PPF: 150 μmol/s

TECHNICAL SPECIFICATIONS

FEATURES

  • Multiple Spectrum LED Diodes

  • Indoor Full Sun Spectrum

  • Input Voltage 100V-277V

  • ETL Certified

  • Uniformity > 90%

  • Ability to daisy-chain fixtures

  • Low Heat Coefficient

  • Wet Rated IP65 for damp areas

  • LED Lifespan 50,000 hours - a long-lasting alternative to a T5

  • Backed by a 5-Year Warranty

  • 24/7 Customer Support

  • Light Type: Multiple Spectrum LED Diodes

  • Spectrum Tuned: Indoor Full Sun / Customized Spectrum

  • Input Power: Smart Sensing™ 100V to 277V

  • Mounting Height: >18” to top of Canopy

  • Emitter Cooling: Passive Thermal Management

  • Waterproof Rating: IP65 for Damp Locations

  • LED Lifespan (90% of Life): 55,000+ Operational Hours


PHYSICAL SPECS

  • Height: 1.14 in /  29 mm

  • Width: 5 in / 130 mm

  • Length: 47.2 in / 1200 mm

  • Lbs: 2.2 lbs / 1kg

"Superior Company, I have been really impressed by, not only the iLW light fixture but the ILUMINAR Lighting customer service. I purchased the 80W model to over-winter my dwarf lime trees.

The Lime trees showed early on that they were quite happy. The only worry I had was having only two rail clips on such long light. So I called ILUMINAR Lighting, and they set me at ease. Wonderful light and outstanding customer service."

MARK

POWER HUB DIAGRAM

If you’re planning on utilizing several LEDs in your room or facility, one of the many benefits of the ILUMINAR Lighting LED horticultural lights is that you can “daisy chain” one fixture to another to save space and use only one outlet to run several lamps thus minimizing the number of cords used in your space.


*Max load power 400w at 120V

*Max load power 800w at 277V

5 YEAR WARRANTY

At ILUMINAR Lighting, we stand behind our products and our technology as well as our customers.

All ILUMINAR Lighting LED fixtures are backed by our 5-Year Guarantee.
